Sentry Series - ISC 20 foot, Internal Cam Clete with Reinforced Raised Door Frame - Rope Halyard. Many options available.

The Sentryl Series from Concord American Flagpole offers Cam Clete Flagpoles in heights from 20' to 40'. The raised reinforced doorframe design provides the security of an Internal Rope Halyard and Cam Cleat System with the reinforced strength necessary for moderate wind speed areas. These flagpoles meet the most stringent architectural standards and are certain to enhance the landscape of any business or industrial property. This 20', single section, flagpole is designed to fly a 4x6 flag and is available in several combinations of Shaft Thickness and Butt Diameters to suit all kinds of wind conditions. Windspeed maximums are listed in "Butt Diameter and Shaft Thickness" Option at the Right. Windage figures are in MPH (Miles Per Hour), Flagged/Unflagged with the recommended size flag.

Standard Features Include:

• Patented, Heavy-Duty Gold Anodized Aluminum Ball
• Cast Aluminum Revolving Truck with SEALED Stainless Steel Bearing Assemblies, Aluminum Pulley and Aluminum Spindle, Cast Brass Exit Bushing and Removable Hood..
• Complete Internal Halyard Assembly - Rope Halyard - 5/16" #10 polyester - Two (2) Stainless Steel Swivel Flagsnaps - Two (2) Neoprene Flagsnap Covers.
• Cam Cleat
• Reinforced Raised Door Frame
• Flush Mount Access Door with Lock and Keys
• Spun Aluminum FC-11 Flash Collar
• Galvanized 16-Gauge Corrugated Steel Ground Sleeve with Steel Grounding Spike.

Optional Upgrades:

• Color and Finish

Satin - Standard -	Clear Anodized	Black Anodized	Dark Bronze Anodized
Bronzetone Powder Coat	Black Powder Coat	White Powder Coat	Clear Powder Coat

• Shaft Thickness

• Heavy-Duty Truck with Dual SEALED Bearings for 4"-8" Butt Diameter Flagpoles

8" or 10" Diameter Ball/Truck Replaces Standard Truck and Ball Combination Cast Aluminum Construction Goldtone Powder Coated Finish Aluminum Pulley on Stainless Steel Axle SEALED Upper and Lower Stainless Steel Ball Bearing Assemblies. 1-1/4" NPT Spindle Factory Attached Eagles Available - Contact us for size and pricing options.

• Collar Options

Our Offering of Heavy-Duty Cast Aluminum Collars Provides Project Owners the Strongest and Most Durable Collar Offered in the Industry Today. Cast from Aluminum Alloy, These 1/4" Thick Cast Collars are Designed to Withstand the Harshest Environments.

• Mount Option

Shoe Bsae Option All 20' to 80' Concord Flagpoles listed on our website with Butt Diameters of 4" or more can be provided with a shoe base option in lieu of the Standard Foundation Sleeve and Lightning Ground Spike. Shoe Bases are welded to the flagpole shaft and heat treated to a T-6 Temper at the factory prior to shipping. For more information and pictuers go here.
